Class I Hospital Emergency Equipment Ceiling Operating Lamp 80000Lux 160000 lux
Contact Person : JUCCY
Phone Number : 0086-17717698563
WhatsApp : +8617717698563
Minimum Order Quantity : | 1pc | Price : | $1999.00 - $2,999.00/Sets |
---|---|---|---|
Packaging Details : | Standard packing | Delivery Time : | about 5 days |
Payment Terms : | T/T, Western Union,Payoneer | Supply Ability : | 5000 Set/Sets per Month Digital phoropter |
Place of Origin: | China | Brand Name: | SUCE |
---|---|---|---|
Certification: | CE,ISO13485 | Model Number: | VT003 |
Detail Information |
|||
Item: | Digital Phoropter | Sphere:: | -29.00~+26.75D(step:0.25D/0.5D/1D/2D/3D) |
---|---|---|---|
Cylinder:: | 0.00~8.75D (step:0.25D/0.5D/1D/2D/3D) | Cylinder Axial:: | 0~180°(step:0.25D/0.5D/1D/2D/3D) |
Working Distance:: | 35~70cm(step:5cm) | Ophthalmoscope:: | +1.5D,+2.0D(measuring Distance67cm,50cm) |
Maddox:: | Right(red/horizon),left(red/vertical) | Red And Green Lens:: | Right Red,left(green) |
Certificate: | CE ISO | Warranty: | 2 Years |
Product Description
Technical Parameter
|
|
|
Measuring range
|
|
|
Sphere:
|
-29.00~+26.75 D(step:0.12D/0.25D/0.5D/1D/2D/3D)
|
|
Cylinder:
|
0.00~8.75D (step:0.25D/0.5D/1D/2D/3D)
|
|
Cylinder axis :
|
0~180°(step : 1/5/15/30/45°)
|
|
PD:
|
Far : 48~80mm Near : 45~75mm (step:0.5/1.0mm)
|
|
Working distance:
|
35~70cm (step: 5 cm )
|
|
Prism:
|
0~20Δ(step 0.1Δ/0.2Δ/0.5Δ/1Δ/2Δ)
|
|
Jackson cross cylinder:
|
Jackson cross cylinder 0.25D Jackson cross cylinder 0.50D
|
|
Dual cross cylinder (separation prism)
|
+1.5D,+2.0D(measuring distance67cm,50cm)
|
|
Ophthalmoscope:
|
+1.5D,+2.0D( measuring distance 67cm, 50cm )
|
|
Size and weight
|
|
|
Body of main engine:
|
362(W)×83(D)×299(H)mm , 3.5kg
|
|
Keyboard:
|
215(W)×230(D)×226(H)mm , 1.5kg
|
|
Junction box:
|
266(W)×72(D)×240(H)mm, 1.3kg
|
|
Package size:
|
600(W)×440(D)×600(H)mm
|
|
Voltage:
|
AC 100~240V, 50/60Hz
|
|
Power:
|
90VA
|
|
Auxiliary lens
|
|
|
Pinhole lens:
|
Φ1mm
|
|
Maddox;
|
Right eye (horizon),left eye (vertical)
|
|
Red and green lens:
|
Right eye(red) , left eye (green)
|
|
Polaroid:
|
Right eye(135°, 45°), left eye (45°, 135°)
|
|
Separation prism:
|
Right eye(6ΔBU), Left eye(10ΔBI)
|
|
Solid suprachiasmatic cylinder :
|
Jackson cross cylinder±0.50D , Axis fixation90°
|
|
Visual degree:
|
32°
|
