criticare patient monitor Aurora 8S 8.4-inch lightweight semi-modular criticare patient monitor for ambulance

Contact Now

criticare patient monitor Aurora 8S 8.4-inch lightweight semi-modular criticare patient monitor for ambulance

Minimum Order Quantity :	10 Pieces	Price :	$460.00 - $999.00/Pieces
Packaging Details :	1 piece load into one carton, 48 pieces of carton put into 1 pallet/patient monitor	Delivery Time :	about 5 days
Payment Terms :	T/T, Western Union,Payoneer	Supply Ability :	3000 Piece/Pieces per Month

Place of Origin:	Jiangsu, China	Brand Name:	Konsung
Certification:	CE,ISO13485	Model Number:	Aurora-8S

Detail Information
Power Source:	Electricity	Warranty:	2 Years
After-sale Service:	Online Technical Support	Material:	Plastic, ABS+PC Fireproof Materials
Shelf Life:	2 Years	Quality Certification:	Ce
Instrument Classification:	Class II	Safety Standard:	GB/T18830-2009
Product Name:	Patient Monitor	Size:	8.4 Inch
Resolution:	800*600 Pixels	Usage:	Medical
Thickness:	8.9cm	Power Supply:	110V/60Hz Or 220V/50Hz
Power Consumption:	100V-240V~,1.0-0.5A	Basic Parameters:	ECG, NIBP, SpO2, RESP, Temp, PR/HR
Option Parameters:	EtCO2, 2IBP, 12 Led ECG	Port:	Shanghai

Product Description

There are warning, lamp flashing & tones alarm on criticare patient monitor.

Long life, industrial grade TFT screen working life upon 50,000h (general less than 20,000h)

Waterproof import from OMRON company life upon 1,000,000 times. (domestic less than 500,000 times)

Industrial shuttle imported from Japanese ALPS company working life upon 1,000,000 times (domestic less than 100,000 times)

Adopted by design of interface hidden with dust cover, it assures the clean of key parts.

720 hours trends, shown as tabulation and graph.

1200 NIBP measurement records

3 – 8 rows of display adjustment

Display switch between Full ECG, Mini trends, OxyCRG and Big Fort

24 kinds of ARR events including sinus arrhythmia, various forms of PVCs, VFIB, VTAC, AFIB, Asystole

Three blocks, neat and reasonable layout inside, good anti-interference performance and easy maintenance

Specification

ECG
Input	3/5 wire ECG cable
Lead section	I II III aVR, aVL, aVF, V
Gain selection	0.25, 0.5, 1, 1.2
Sweep speed	6.25mm/s, 12.5mm/s, 25mm/s, 50mm/s
Heart rate range	15-30bpm
Calibration	±1mv
Accuracy	±1bpm or ±1% (select the bigger data)
NIBP
Test method	Oscillometer
Philosophy	Adult, Pediatric and Neonate
Measurement type	Systolic Diastolic Mean
Measurement parameter	Automatic, Continuous measurement
Measurement method Manual	mmHg or ±2%
SPO2
Display Type	Waveform, Data
Measurement range	0-100%
Accuracy	±3% (between 70%-100%)
Pulse rate range	20-300bpm
Accuracy	±1bpm or ±2% (select the bigger data)
Resolution	1bpm
2-Temperature (Rectal & Surface)
Number of channels	2 channels
Measurement range	0-50℃
Accuracy	±0.2℃
Display	T1, T2, ☒T
Unit	ºC/ºF selection
Refresh cycle	1s-2s
Respiration (Impedance & Nasal Tube)
Measurement type	0-150rpm
Accuracy	±1bm or ±5%, select the bigger data
Resolution	1rpm
Packing Information
Packing size	333328cm
N.W.	4kg
G.W.	5kg

Optional Parts

EtCO2

◆ETCO2 is the amount of carbon dioxide (CO2) in exhaled air, which assesses ventilation.
◆A high ETCO2 is a good sign of good ventilation, while low ETCO2 is bad sign that represents hypoventilation.

2IBP

◆With Template self-adapting technique, which ensure the accuracy in complicated clinic conditions. Solve the problem that NIBP of most brand patient monitor cannot measure stably and accurate when patients have arrhythmia and rapid changing pulse. The anocelia and intracranial will be monitored at the same time.

Trolley

◆The stand is made of high-quality aluminum alloy with max load of 25kg. It can be adjusted up and down, rotated left and right, and the pitch angle can be adjusted by 15 degrees. The replaceable slip plate design is applied for most of monitor with screw at the bottom
◆The main body of this cart is made of high quality aluminum alloy and stainless steel material, which has good corrosion-resistance.
◆With lifting design, it can be used in different heights.

Thermal Printer

◆Installed on the back of patient monitor, detachable.
◆Suitable to thermal paper.

Packing & Delivery

To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.

Title goes here.

Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.

FAQ

1.Can the accessories be exchanged between both Aurora and Aurora S series?
Yes, it is possible to use the same accessories across both Aurora and Aurora S.

2. Can the monitors display wave-forms and numerical data?

Yes, both monitors of Aurora and Aurora S can display wave-forms and numerical data.

3. How many waveforms can be displayed on the screen?

The screen can display up to a maximum of 8 wave-forms.

4. Are the batteries a cost option?

No, the battery is included in the basic price of the system.

5. What types of batteries are used?

Both systems use a high capacity built-in rechargeable lithium battery.

6.Can the monitors connect to printer?

Aurora series cannot connect to printer, and Aurora S series can connect to printer.

7. Can the monitors support Wifi?

Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.

8. Which kind of options parts can you offer?

We can offer touch screen, IBP, 2IBP, EtcO2, Printer, wall mount and trolley.

Why Choose Us

1. Durable

Monitor is made of ABS+PC Fireproof Materials

2. Ultra-thin design

8.9cm thick, smaller footprint

3. Low consumption

Adopted by the design of fanless, heat fast.

4. Quality assurance

Both Aurora and Aurora S series have passed CE approval.

5.Silicone button

Adopted by pure flat silicone button for easy cleaning.
