2019 NEWEST products ophthalmic surgical instruments Precise eye laser Photocoagulator

Minimum Order Quantity :	1PC	Price :	$15,999.00 - $18,000.00/Pieces
Packaging Details :	Standard box package	Delivery Time :	about 10 days
Payment Terms :	T/T, Western Union,Payoneer	Supply Ability :	5000 Set/Month

Place of Origin:	China	Brand Name:	SUCE
Certification:	CE,ISO13485	Model Number:	OEM

Detail Information
Instrument Classification:	Class I	Type:	Ophthalmic Optical Equipments, Frequency-doubling Nd:GdVO4 Laser
Product Name:	Laser Photocoagulator	Certificate:	ISO13485 And CFDA
Wavelength::	532nm Green True CW	Power Output::	50~1200mW, Adjustable
Pulse Duration::	0.01s~3s, Adjustable	Pulse Interval::	0.05s~1s, Adjustable
Dimension::	30cm X 28cm X 14cm	WhatsApp:	008618024582853
Power:	100~240VAC

Product Description

2019 NEWEST products ophthalmic surgical instruments Precise eye laser Photocoagulator

Features of Laser Photocoagulator

Compact

Compact and portable design for advanced solid-state-laser technology

Touch-screen operations for easier use

Precise

Continuously zoomed and precise laser spot size

Homogenous photocoagulation spot on retina

Stable output but no power degeneration for closed-loop power control system

Safe

Minimized power density on cornea

Maximum protection while maintaining clear field view

Adaptable

Detachable delivery system, compatible with a range of slit lamp microscopes

Clinical Application

The Laser photocoagulation leverages the photo-thermal effect, one of laser biological effects, to treat abnormal retinal tissues which are damaged through thermo-coagulation and scar for purposes of treating ocular fundus diseases.

Components

Nd:GdVO4 Laser Photocoagulator (Laser Photocoagulator) comprises a laser console, footswitch, delivery devices, an external door interlock and a main power cable, wherein the delivery device is receptacles for slit lamp adaptor.

Technical Parameters

Treatment Beam :
Type:	Frequency-doubling Nd:GdVO4 Laser
Wavelength:	532nm Green True CW
Power Output:	50~1200mW, adjustable
Pulse Duration:	0.01s~3s, adjustable
Pulse Interval:	0.05s~1s, adjustable
Aiming Beam
Type:	Laser diode
Wavelength:	630~680nm
Power output:	<1.0mW, adjustable
Cooling:	Air Cooled, theremoelectric cooler system
Laser Delivery Unit:	Slit lamp adapter
Slit Lamp Delivery:	Haag Streit style slit lamp
Spot Size:	Continuously adjustable from 50 to 500 microns
Power:	100~240VAC
