Class I Hospital Emergency Equipment Ceiling Operating Lamp 80000Lux 160000 lux
Contact Person : JUCCY
Phone Number : 0086-17717698563
WhatsApp : +8617717698563
| Minimum Order Quantity : | 1pc | Price : | $11,000.00 - $15,874.00/Sets |
|---|---|---|---|
| Packaging Details : | standard export carton package | Delivery Time : | about 10 days |
| Payment Terms : | T/T, Western Union,Payoneer | Supply Ability : | 5000 Set/Sets per Month Surgical Ophthalmic Microscope |
| Place of Origin: | China | Brand Name: | SUCE |
|---|---|---|---|
| Certification: | CE,ISO13485 | Model Number: | SX16 |
|
Detail Information |
|||
| Warranty: | 3 Years, 2 Years | Customized Support: | OEM, ODM |
|---|---|---|---|
| Theory: | Video Microscope | Drawtube: | BINOCULAR |
| Item: | Magnification Camera Adapter Biom Ent Ophthalmic Surgical Microscope | Eyepiece Magnification: | 12.5x |
| Working Distance: | F=200 | Cylinder: | 190mm |
| Magnifications For Main Microscope: | 5.3x,8x,12x | Adjustable Diopter: | ±7D |
| Adjustable Range Of Pupil Distance: | 50mm~80mm | Certificate:: | CE ISO |
| Maximal Resolution: | 100LP/mm | ||
Product Description
|
Specifications
|
|
|
|
Eyepiece Magnification
|
12.5×
|
|
|
Objective Lens
|
f=200
|
|
|
Working Distance
|
190mm
|
|
|
Magnifications for Main Microscope
|
5.3×,8×,12×
|
|
|
Diameter of Field
|
37mm,25mm,16.7mm
|
|
|
Adjustable Diopter
|
±7D
|
|
|
Adjustable Range of Pupil Distance
|
50mm~80mm
|
|
|
Maximal Resolution
|
100LP/mm
|
|
|
Illumination Source
|
12V/100W,medical cold reflection halogen lamp
|
|
|
Illumination Type
|
6°+0°Coaxial cold light source illumination
|
|
|
Coaxial Illumination
|
≥30000lx
|
|
|
Reaching Radius of Arm
|
870mm
|
|
|
Adjustable Vertical Range
|
700mm~1100mm
|
|
|
Fine Focusing Range
|
30mm
|
|
|
Voltage
|
AC220V V / 50Hz1Hz,AC110VV /60Hz1Hz
|
|
|
Power
|
120VA
|
|
|
Fuse
|
AC250V T1.25A ,AC125V T2.5A
|
|
|
Electrical Safety Standard
|
Executive Standard: GB9706.1-2007,type I
|
|
|
Packing Volume
|
0.2m3,1carton
|
|
|
Total Gross Weight
|
41kg
|
|
