H7-3 invasive digital portable hemoglobin meter with test strips

Contact Now

H7-3 invasive digital portable hemoglobin meter with test strips

Name: H7-3 invasive digital portable hemoglobin meter with test strips
Brand: Konsung
SKU: H7-3
Price: 300.00 USD
Availability: InStock
Rating: 5 (145 reviews)

Minimum Order Quantity :	1pc	Price :	$300.00/Pieces 1-9 Pieces
Packaging Details :	Packing in carton/portable hemoglobin meter	Delivery Time :	about 10 days
Payment Terms :	T/T, Western Union,Payoneer	Supply Ability :	3000 Piece/Pieces per Month

Place of Origin:	Jiangsu, China	Brand Name:	Konsung
Certification:	CE,ISO13485	Model Number:	H7-3

Detail Information
Type:	Blood Analysis SYstem, Blood Testing Equipments	Instrument Classification:	Class II
Warranty:	2 Years, 3 Years (about 20 Samples Per Day) Or 22,000 Tests	After-sale Service:	Online Technical Support
Product Name:	Portable Hemoglobin Meter	Parameters:	Hb And HCT
Working Environment:	-20°C~60°C	Relative Humidity:	≤90%
Battery:	Lithium Battery	Power Supply:	DC3.7V Rechargeable Lithium Battery
Usage:	Clinic	Material:	ABS Plastic + Electronic Components
Port:	Shanghai Port

Product Description

Specification

Principle	Microfluidic and spectrometer with scattering compensation technology
Inspection time	≤3s
Measurement range	0–25.6 g/dL
Precision	CV≤1.5%
Accuracy	≤3%
Interface	USB, Bluetooth, wifi, printer
Operating Conditions	15°C～35°C, RH≤85%
Storage condition	-20°C～60°C, RH≤90%
Dimension	13cm8.2cm3.15cm
Packing size	17.6cm12.5cm10.5cm
N.W.	0.22kg
G.W.	0.5kg

Features:
◆Immediate HB and Hct results: ≤3 seconds
◆Hand-held size with lab-quality accuracy: CV≤1.5%
◆Low sample volume: 7µl (capillary or venous blood)
◆Large memory stores: up to 2000 test results
◆Long time using with built-in battery: more than 6 hours
◆Easy and simple operation: 3 steps only
◆Reagent-free cuvette with long shelf life: 2 years
◆Ready to use, No coding needed

Product Description

Smart TFT color screen

True color screen, intelligent voice, humanized experience, data changes are always at hand

ABS+PC material is hard, wear resistant and antibacterial

White appearance is not affected by time and use, and highly in antibacterial properties

Precision test result

The precision of our hemoglobin analyzer CV≤1.5%, because adopted by quality control chip for the internal quality control.

Unique Microfluidics, the top domestic craft

Unique disposable microfluidic chip, one-time use, completely eliminate carry pollution.

Small volume of blood test

7uL of blood volume is enough to support one test.

Get test result within 3 seconds

Within 3 seconds, HB analyzer will show your results on the big TFT display.

Big data storage

It can support storage of 2000 results.

Large physical button, permanent magnet suction feedback processing unit

After millions of tests, button is still as sensitive as ever

Installation reference

Packing & Delivery

To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.

FAQ

1. What is the meaning of error 07?

Error 07 means test chip is blank or no test chip. You should put new test chip into the device.

2. How we inform the device if we test male, female or children?

The device cannot recognize the source of the sample is adult or child sex…only for the sample which the value is more than 175 and less than 115, the interpretation recommendations of the results are based on the reference range.

3. How long we can use if we recharge full energy in one time?

You can use 6 hours, that means you can test more than 200 persons.

4. Can the hemoglobin analyzer connect to printer?

Yes, the hemoglobin analyzer can connect to thermal printer.

5. How to clean inner slot?

Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine It would be better by isopropanol and ethanol.
